Description

S-LINE Linear Lighting system is an energy-efficient and cost effective light solution for industrial, commercial and other indoor applications.

Made as simple as possible giving up with unnecessary components, but still with good quality of light and high lumen output. Designed to be used in a continious line, or as independant luminarie.

Do you want to know more?

Click to access our Contact Us page where you can send us an enquiry.

Make enquiry

Product details

  • Type

    S-LINE

  • Material

    Housing - aluminum extrusion, painted.

  • Light source

    Mid power LEDs

  • Operating temperature

    - 20 °C ≤ Ta ≤ + 35 °C

  • Light color

    3000K-4000K-5000K

  • Lifetime

    L90B10 >100000 h (Ta = 25°C)

  • Color Rendering Index

    Ra ≥ 80

  • Remarks

    Luminaries are ready to install

  • Power consumption

    30 W , 40 W, 55 W, 60 W, 70 W, 75 W, 80 W

  • Optical cover

    PMMA. 30, 60, 90 degrees, 60x90 and 90x110 asymetric.

  • Efficacy

    Up to 167 lm/W

  • Driver

    Tridonic - 230V

  • Size

    600 mm x 50 mm x 49 mm; 900 mm x 50 mm x 49 mm; 1200 mm x 50 mm x 49 mm; 1500 mm x 50 mm x 49 mm.

  • Interfaces

    DALI/DMX

  • Control type

    Driver On/Off
