OREON

1000A 2
Gallery navigation
Gallery navigation

Premium quality Park LED luminaires. Up to 6350Lm / 45-80W.

More detailed information is being prepared. Please contact us to find out more

Choose the info

Overview arrow
Downloads arrow
OREON

Product Color

RAL 7016

Description

OREON LED luminaires are designed to illuminate pedestrian paths, squares, parks, and other public spaces, combining aesthetics with high energy efficiency. They feature the following key characteristics. The die-cast aluminum housing, LEDs, and technological solutions ensure a long service life. Options for different color temperatures and color rendering indexes (CRI) are available. Standard power ranges from 45W to 80W.

Applications

OREON LED luminaires are designed to enhance the environment with their aesthetic appearance while ensuring uniform, shadow-free lighting.

Technical information

Electrical
V
Input voltage
110-240
Hz
Frequency
50-60 Hz
W
Luminaire wattage
45-80
Cosφ
Power factor
≥ 0.95
Optical
Lm
Luminous flux
3285-6350
CCT K
Color temperature
3000/4000
Ta
Performance temperature
- 40 °C ≤ Ta ≤ + 50 °C
CRI˚
Color rendering index
≥70
Housing
Size
560mm x H265mm x 60mm
Weight Gross
4,0 kg
Weight Net
5,0 kg
Body material
Die-cast aluminium housing. Opal PC diffuser.
Protection against fogging
IK08
Optics
Optical cover
Opal PC diffuser.
Light source
LED
Maintenance
Optical module sealed for life No internal cleaning required
Remarks
Chromatic tolerance (original MacAdam)
Not higher than 5
Life expectancy L/B
L90 B10 by 100000 hrs (Ta = 25 °C)
Warranty
5 year

Do you want to know more?

Send us an enquiry.

info@enimlighting.com

Do you want to know more?

Send us an enquiry.

info@enimlighting.com

Do you want to know more?

Send us an enquiry.

info@enimlighting.com

Do you want to know more?

Send us an enquiry.

info@enimlighting.com
Luminaire dimensions/ cm Pallet size/cm L*W*H Luminaires per row, units Number of rows on the pallet QTY per pallet/pcs Kg per pallet Volume per pallet, m3 LDM, m
Net Gross
56,0 x H26,5 x 9,1 120x80x180 6 2 12 63 75 1,728 0,4
Package size/cm L*W*H Kg per package Volume per package, m3
Net Gross
70,0 x 40,0 x 40,0 4,0 5,0 0,112
